SPECIFICATIONS

Power Source

• Auxiliary Power 12 Volts DC

• Capacity - Fuel Tank 40 gal. / 151.42 L

• Engine Type - Diesel DEUTZ TD 2.9L Tier 4 Final 67 hp

• Engine Type - Dual Fuel GM Vortec 3000 MPR 82 hp


Performance

• Platform Capacity -
  Restricted 1000 lb / 453.59 kg

• Platform Capacity -
  Unrestricted 500 lb / 226.80 kg
  Swing 360 Degrees


Dimensional Data

• Machine Height 8 ft 5 in. / 2.56 m

• Machine Length 28 ft 5 in. / 8.65 m

• Machine Width 8 ft 2 in. / 2.49 m

• Platform Dimension A 3 ft / 0.91 m

• Platform Dimension B 8 ft / 2.44 m

• Platform Height 60 ft 3 in. / 18.36 m


Reach Specifications

• Horizontal Jib Rotation 0 Degrees

• Horizontal Outreach 49 ft 6 in. / 15.09 m

• Platform Height 60 ft 3 in. / 18.36 m
