SPECIFICATIONS

• W x L x H - 5.5 x 10 x 7.5

• Weight - 5,000 lbs

• Tank Capacity - 25 bbl

• Horsepower - 30 HP

• Voltage - 480 V 3PH

• Motor - 30 HP Texp 1800 RPM 480 V 60 HZ

• Drive - Timing Belt Style Positive Drive 1.5:1 Ratio

• Blower - Jurop RV 520 520 CFM

• CFM - 18 HG 15 PSI

• Requires a 100 Amp breaker to operate

• Max Vacuum - 20 Inches of Mercury

• Max Pressure -15 PSI

• Classification - Class 1 Div 1 Group C&D

• Voltage - 480

• Frequency - 60 HZ

• Full load Amps - 39 Amps

• Suction Conveyance - 25 + Tons Per Hour

• Discharge Conveyance 200 GPM
